Consent System Diagrams

Architecture Diagram

Sequence Diagram

Class Diagram

Flow Description

User Consent Status Flow

1. Northstar App fetches required consents from consent configurations
2. Northstar App requests the EYFP Consent Service for user consent agreements
3. EYFP Consent Service authorizes the request through EYFP Auth Service
4. EYFP Auth Service validates the token with VAS Auth Service
5. EYFP Consent Service fetches user's consent agreements from EYFP Consent Agreement Service
6. Each ConsentAgreement object provides its status through the getStatus() method (Granted, Not granted, Revoked, Deleted, Outdated)
7. The consent agreements with computed status are returned to the Northstar App

Consent Content Flow

1. If user has not given consent or revoked it, Northstar App fetches versioned consent content
2. EYFP Consent Service authorizes the request using the EYFP Auth Service
3. EYFP Auth Service validates the API key internally
4. EYFP Consent Service fetches the latest consent content from EYFP Consent Content Service
5. EYFP Consent Service returns the content to Northstar App for display to the user

where to keep the consent config

we will keep the config in the product config area , and will be exposed as a seperate api via FECommons API.

Consent Status Logic

The consent status is computed dynamically from the ConsentAgreement properties using the getStatus() method. This eliminates the need for a separate status table and ensures data consistency. The status determination follows this priority order:

Status Computation Rules

Status	Condition	Description	Storage Decision
DELETED	isDeleted = true	User's consent record has been permanently deleted (GDPR compliance)	Stored (for audit trail)
REVOKED	isRevoked = true AND isDeleted = false	User has explicitly withdrawn their consent	Stored (explicit action)
NOT_GRANTED	granted = false AND isRevoked = false AND isDeleted = false	User has explicitly declined the consent	Stored only for explicit declines
NEVER_ASKED	No record exists	User has never been presented with this consent	Not stored (no record)
OUTDATED	granted = true AND isRevoked = false AND isDeleted = false AND version < latestVersion	User granted consent but for an older version - requires re-consent	Stored (shows consent history)
GRANTED	granted = true AND isRevoked = false AND isDeleted = false AND version = latestVersion	User has granted consent for the current version	Stored (active consent)

Storage Strategy

What gets stored in ConsentAgreement table:

• ✅ Explicit Grant: User clicks "Accept" → granted = true

• ✅ Explicit Decline: User clicks "Decline" → granted = false

• ✅ Revocation: User withdraws consent → isRevoked = true

• ✅ Deletion: GDPR deletion request → isDeleted = true

• ❌ Never Asked: No user interaction → No record created

• isActive(): Returns true if status is GRANTED (consent is valid and current)

• isOutdated(latestVersion): Returns true if user granted consent but for an older version

Business Rules

1. Deletion takes precedence: Once isDeleted = true, status is always DELETED regardless of other fields
2. Revocation overrides grant: If isRevoked = true, status is REVOKED even if granted = true
3. Version checking: Only applies when consent is granted and not revoked/deleted
4. Re-consent requirement: OUTDATED status indicates user must provide consent again for the new version
5. Automatic revocation on upgrade: When a user grants consent to a new version, the old version agreement is automatically revoked (isRevoked = true) to maintain clean consent history

Example Scenarios

granted	isRevoked	isDeleted	version	latestVersion	Record Exists	Status	Action Required
true	false	false	"1.0"	"1.0"	Yes	GRANTED	None
true	false	false	"1.0"	"2.0"	Yes	OUTDATED	Re-consent for v2.0
false	false	false	"1.0"	"1.0"	Yes	NOT_GRANTED	User explicitly declined
true	true	false	"1.0"	"1.0"	Yes	REVOKED	User withdrew consent
true	false	true	"1.0"	"1.0"	Yes	DELETED	Cannot process - data deleted
N/A	N/A	N/A	N/A	"1.0"	No	NEVER_ASKED	Present consent for first time

Key Insight: The difference between NOT_GRANTED and NEVER_ASKED is crucial:

• NOT_GRANTED: User saw the consent and explicitly clicked "Decline" - we store this decision
• NEVER_ASKED: User has never been presented with this consent - no database record exists
• OUTDATED: User previously agreed to v1.0, but now v2.0 is available - they need to see and agree to the new version

Version Upgrade Process

When a user with OUTDATED status agrees to a new consent version:

1. Old Agreement Handling: The previous agreement is automatically revoked:

   UPDATE consent_agreement
   SET isRevoked = true,
       revokedTimestamp = NOW(),
       revokedReason = 'VERSION_UPGRADE'
   WHERE userId = ? AND consentId = ? AND version = 'old_version'

2. New Agreement Creation: A new agreement record is created:

   INSERT INTO consent_agreement
   (userId, consentId, granted, version, contentversion, timestamp, consentContent, tenantID)
   VALUES (?, ?, true, 'new_version', ?, NOW(), ?, ?)

3. Audit Trail: Both the revocation and new agreement are logged for compliance

Core Consent System Requirements

Consent Agreements

• Definition: A consent "agreement" is created when a user accepts or rejects a consent request
• Support Tools: Consent management services must allow support tools to create and process consents without requiring a user token
• Audit Trail: All agreements must be stored in a logged, timestamped, audit-proof, and immutable manner
• Digital Signature: Each agreement must include a cryptographic signature or hash that:
  • Verifies the specific content the user agreed to
  • Proves if consent content has been modified after agreement
  • Is cryptographically immutable

Versioning System

Consent content in EYFP is managed using a two-level versioning system:

1. Consent Version

• Represents major changes to consent conditions
• Managed through the admin portal
• When a user hasn't granted consent or has granted an earlier version:
  • The latest consent version is presented
  • Upon agreement, this version is recorded
• A new consent version always requires re-consent from users

2. Content Version

• Handles minor changes within a consent version
• Characteristics:
  • Increments with small text or formatting changes
  • Exact content shown to user is preserved with the agreement
  • Users always see the latest content version of a given consent
• Important: Content version changes do not require re-consent if a user has already agreed to the parent consent version
• Only users who haven't yet granted consent will see updated content versions

Regular Error Handling for the API

Success Codes

Code	Description	Example Usage
200 OK	Successful request. The server has fulfilled the request and is returning the requested data.	GET user consents, PUT/update consent status
201 Created	The request has been fulfilled, and a new resource has been created. The response typically includes a Location header pointing to the newly created resource.	POST new consent agreement
204 No Content	The request was successful, but there is no response body to return.	DELETE consent record, successful revocation

Error Codes

Code	Description	Example in Consent System
400 Bad Request	The client's request is malformed, invalid, or cannot be processed. This includes validation errors, missing required fields, or invalid data formats.	Invalid consent ID format, missing required user ID
401 Unauthorized	Authentication is required but was not provided or was invalid. The client must authenticate to access the resource.	Invalid or expired auth token when accessing consent services
403 Forbidden	The client is authenticated but does not have permission to access the requested resource or perform the requested action.	User attempting to access another user's consent records
404 Not Found	The requested resource does not exist on the server.	Consent ID not found, user has no consent records
405 Method Not Allowed	The HTTP method used is not supported for the requested resource.	Using DELETE on an endpoint that only supports GET/POST
409 Conflict	The request conflicts with the current state of the resource on the server.	Attempting to create a consent that already exists
422 Unprocessable Entity	The request was well-formed but contains semantic errors that prevent processing.	Consent data is valid but conflicts with business rules
429 Too Many Requests	The client has sent too many requests in a given amount of time ("rate limiting").	Exceeding API rate limits for consent operations
500 Internal Server Error	An unexpected error occurred on the server that prevented it from fulfilling the request.	Database failure, unexpected exception in consent service
503 Service Unavailable	The server is temporarily unable to handle the request due to maintenance or overload.	Consent service under maintenance or experiencing high load
504 Gateway Timeout	The server, acting as a gateway or proxy, did not receive a timely response from an upstream server.	Timeout when communicating with dependency services

Exception Format

All error responses from the Consent Management APIs will follow this standard format:

{
  "error": {
    "code": "ERROR_CODE",
    "message": "Human-readable error message",
    "details": [
      {
        "field": "fieldName",
        "issue": "Specific issue with this field",
        "location": "body"
      }
    ],
    "traceId": "unique-request-identifier",
    "timestamp": "2025-08-19T12:34:56.789Z"
  }
}

Example Error Responses

400 Bad Request - Missing Required Field:

{
  "error": {
    "code": "INVALID_REQUEST",
    "message": "The request is missing required fields",
    "details": [
      {
        "field": "consentId",
        "issue": "Field is required",
        "location": "body"
      }
    ],
    "traceId": "abcd1234-5678-90ef",
    "timestamp": "2025-08-19T10:15:30.123Z"
  }
}

401 Unauthorized - Invalid Token:

{
  "error": {
    "code": "AUTHENTICATION_FAILED",
    "message": "Invalid or expired authentication token",
    "details": [],
    "traceId": "efgh5678-1234-56ij",
    "timestamp": "2025-08-19T14:22:10.456Z"
  }
}

404 Not Found - Consent Not Found:

{
  "error": {
    "code": "RESOURCE_NOT_FOUND",
    "message": "The requested consent does not exist",
    "details": [
      {
        "field": "consentId",
        "issue": "No consent found with ID 'privacy-2025'",
        "location": "path"
      }
    ],
    "traceId": "ijkl9012-3456-78mn",
    "timestamp": "2025-08-19T16:45:20.789Z"
  }
}

add Agreememt management tool ( similar to consent support ) inside admin UI and connect
